Electrode inverter CRAFT-STICK 253

€785,97 EUR (€639,00 excl.Vat)

Tax includedShipping calculated at checkout

SKU: 1073253 Barcode: 4036351250128

14 Day
Return Policy

Warranty

12 months

Fast
Delivery

Sold Out
Description Features Delivery contents Shipping
Electrode inverter CRAFT-STICK 253.
  • All devices are built in modern inverter technology
  • Best suited for assembly work (on ladders, scaffolding. ) and due to protection class IP 21S generally also for outdoor work
  • Suitable for use on the generator e. in operating workshops, ports, chemical plants, schools, metal construction, on construction sites, ships or for farmers
  • Protection against moisture, salt spray and corrosion due to sealed circuit board. Therefore also suitable offshore
  • Hot Start: By adjustable short-.
  • Cable length 2,2 m
  • Current at 100% DC 40°C TIG DC 200 A
  • Current at 100% DC 40°C electrode 200 A
  • Duty cycle at Imax. 40°C TIG DC 60 %
  • Duty cycle at Imax. 40°C electrode 60 %
  • Efficiency 89 %
  • Frequency 50/60 Hz
  • Height 350 mm
  • Input current TIG 13.1 A
  • Input current electrode 17.7 A
  • Length 495 mm
  • Negative mains voltage tolerance 10 %
  • Net weight 11.8 kg
  • Open circuit voltage MMA 70.1/ TIG 69.4 V
  • Positive mains voltage tolerance 10 %
  • Power consumption TIG DC 6.3 kVA
  • Power consumption electrode 8.5 kVA
  • Power consumption in idle mode < 50 W
  • Required generator output >10 kVA
  • Setting range TIG DC 20 – 250 A
  • Setting range electrode 20 – 250 A
  • Supply voltage 400±10% V
  • Total output TIG 7.4 kVA
  • Total output electrode 10 kVA
  • Weldable electrodes 1,6 - 5,0 mm
  • Width 190 mm
  • 3 m welding cable 25 mm² with electrode holder 300 A
  • 3 m ground cable 25 mm² with ground terminal 300 A
