Cylindrical grinding machine OPTIgrind GC 1305

• Frequency 50 Hz
• Grinding diameter with internal bezel 35 - 100 mm
• Grinding diameter with steady rest 8 - 60 mm
• Grinding diameter without bezel inside 25 - 100 mm
• Grinding diameter without steady rest 8 - 200 mm
• Grinding length 500 mm
• Headstock swivel range 0 - 45 °
• Height 1500 mm
• Internal grinding depth 125 mm
• Length 2250 mm
• Max. workpiece weight 50 kg
• Motor power 4 kW
• Net weight 2200 kg
• Spindle taper MT 4
• Stepless table feed in the longitudinal axis 0.1 - 4 mm
• Supply voltage 400 V
• Swivel range of the worktable Right / Left +3 / -9 °
• Tailstock taper MT 4
• Tip height 135
• Travel per graduation mark of the handwheel 0.005 mm
• Travel per revolution of the handwheel 1 mm
• Traverse path quills 25 mm
• Width 1600 mm
• Work spindle Speed range 25 - 380 min¯¹
• Work table travel max. 640 mm
