Motorized sheet metal shears MTBS 1350-30 T

• Absorbed motor power 3,5 kW
• Air consumption per cycle 10 l
• Cutting angle 2,2 °
• Cutting kerf adjustment max. 0,4 mm
• Cutting kerf adjustment min. 0,05 mm
• Cutting performance (400 N/mm²) 3 mm
• Cutting performance (450 N/mm²) 3 mm
• Cutting performance (700 N/mm²) 1,5 mm
• Delivery power 3 kW
• Duty type drive motor S1
• Frequency 50 Hz
• Height 1110 mm
• Length 2070 mm
• Machine body depth 680 mm
• Max. strokes for full cutting length 40 /min
• Motor duty cycle 100 %
• Motor output rear stop 0,37 kW
• Net weight 1190 kg
• Rear stop range 750 mm
• Rear stop speed 28 mm/s
• Sheet support arms 2 St
• Side stop length 1000 mm
• Supply voltage 400 V
• Table depth 420 mm
• Table height 800 mm
• Table length 1507 mm
• Total current draw 7,82 A
• Total rated value 4 kW
• Width 2120 mm
• Working width 1350 mm
