Stationary auxiliary piston compressor (15 bar) AIRPROFI 753/13/15

€2.938,47 EUR (€2.389,00 excl.Vat)

Tax includedShipping calculated at checkout

SKU: 2029851 Barcode: 9006248010710

14 Day
Return Policy

Guarantee

12 months

Fast
Delivery

Sold Out
Description Features Delivery contents Shipping
Stationary auxiliary piston compressor (15 bar) AIRPROFI 753/13/15.
The reason for this is that, according to experience, 90% of all users have an operating pressure of max. 13 bar
  • Any additional pressure generated means an energy consumption of about 8% per bar.
  • If you still need the maximum pressure of 15 bar, you can easily do it yourself at any time at the pressure switch.


    • .
    • Air outlet 3/4 "
    • Compressor speed 785 min¯¹
    • Condensate drain 3/8" ball valve
    • Explanation filling capacity at 6 bar working pressure
    • Explanation sound pressure level Lp Sound pressure level at 1 m distance according to DIN 45635 T 13
    • Filling capacity 525 l/min
    • Frequency 50 Hz
    • Height 745 mm
    • Length 685 mm
    • Maximum pressure 15 bar
    • Motor output power 5.5 kW
    • Motor power (input power) 6.5 kW
    • Net weight 75 kg
    • Number of compressor stages 2
    • Number of cylinders 2
    • Pressure vessel capacity 13 l
    • Sound pressure level 82 dB(A)
    • Suction capacity 750 l/min
    • Supply voltage 400 V
    • Width 790 mm
