Surface and thickness planer ADH 31C Spiral (230 V)

€3.430,47 EUR (€2.789,00 excl.Vat)

Tax includedShipping calculated at checkout

SKU: 5904033 Barcode: 4036351362869

14 Day
Return Policy

Warranty

12 months

Fast
Delivery

Sold Out
Description Features Delivery contents Shipping
Surface and thickness planer ADH 31C Spiral (230 V)..
  • Absorbed motor power 2.84 kW
  • Extraction port diameter joints 100 mm
  • Extraction port diameter thickness 100 mm
  • Feed speed 7 m/min
  • Frequency 50 Hz
  • Height 1010 mm
  • Infeed table length 1295 mm
  • Infeed table width 325 mm
  • Length 1300 mm
  • Max. cutting depth of joints 3 mm
  • Max. cutting depth thickness 3 mm
  • Max. planing width 308 mm
  • Net weight 210 kg
  • Number of planing blades 56
  • Output power 2.2 kW
  • Planing shaft diameter 70 mm
  • Planing shaft speed 5200 min¯¹
  • Planing stop pivoting range 90 - 45 °
  • Supply voltage 230 V
  • Thicknessing table length 545 mm
  • Thicknessing table width 308 mm
  • Width 720 mm
  • Working height 850 mm
  • Working height max. thickness 225 mm
  • Working height min. thickness 5 mm

Add content using the options to the left

Shipping to Ireland & UK.

To see the exact shipping price for this product Add the product to cart. Then add your location and other details for the shop to calculate shipping costs to you.

Our two rates are €10.00 for shipments up to 30kg and the €60 for all shipments over 30kg weight.

€10 is via DPD and the €60 is via pallet express.

Free shipping on all online orders over €100.00

You can also pick up an item for free from our Longford store.

All orders (stock items) for Standard delivery are normally despatched within one to two working days from clearance of payment.

We expect delivery to be within 2 to 5 working days thereafter.

Standard Delivery will be by Courier service for orders up to 30kg in weight.
