Holzstar

• Vertical stroke 160 mm
• Drilling width 250 mm
• Max. drilling depth at 90° 210 mm
• Net weight 96 kg
• Table length 500 mm

Holzstar

• Vertical stroke 120 mm
• Drilling width 160 mm
• Max. drilling depth at 90° 160 mm
• Net weight 68 kg
• Table length 370 mm

Holzkraft

• Speeds 250 – 850, 430 – 1450, 950 – 3200 min-¹
• Motor power input 0.7 kW
• Bearing distance 95.5 mm
• Frequency 50 Hz
• Frequency inverter ✔

Holzkraft

Optimum

• Thermal drill max. material thickness 3.5 mm
• Thermal drill thread M6
• Thread tapper size M6 x 1.0

Metallkraft

• Max. bending performance in steel 400 N/mm² 4 mm
• Roller speed 5 m/min
• Collar width 200 mm
• Height 1200 mm
• Net weight 500 kg

Metallkraft

• Holder diameter 19 mm
• Morse cone MK 3
• Net weight 380 G

Aircraft

• Motor power (input power) electric motor 2.2 kW
• Air outlet 1/2 "
• Effective delivery volume 240 l/min
• Explanation sound pressure level Lp Sound pressure level at a distance of 1 m according to DIN 45635 T 13
• Filling quantity of oil 2.2 l

Metallkraft

Aircraft

• Motor power (input power) electric motor 4 kW
• Air outlet 1/2 "
• Effective delivery volume 485 l/min
• Explanation sound pressure level Lp Sound pressure level at a distance of 1 m according to DIN 45635 T 13
• Filling quantity of oil 2.2 l

Aircraft

• Motor power (input power) electric motor 4 kW
• Air outlet 1/2 "
• Effective delivery volume 580 l/min
• Explanation sound pressure level Lp Sound pressure level at a distance of 1 m according to DIN 45635 T 13
• Filling quantity of oil 2.2 l

Optimum

• Clamping height 40 mm
• Length without crank 216 mm
• Construction height 74 mm
• Max. length ca. 460 mm
• Deep hole width 12 mm

Optimum

• Clamping height 64 mm
• Length without crank 406 mm
• Construction height 118 mm
• Max. length ca. 788 mm
• Deep hole width 16 mm

Optimum

• Thermal drill max. material thickness 2.5
• Thermal drill thread 1/4 "
• Thread tapper pitch 20 TPI
• Thread tapper size 1/4"
• Thread tapper total length 90 mm

Optimum

• Thermal drill max. material thickness 2.5 mm
• Thermal drill thread M12

Holzkraft

• Saw band length 6090 mm
• Delivery power 5.5 kW
• Extraction port diameter 2 x 140 mm
• Flywheel diameter 840 mm
• Frequency 50 Hz

Optimum

• Thermal drill max. material thickness 2.0 mm
• Thermal drill thread M6
• Thread tapper size M6 x 1.0

Optimum

• Thermal drill max. material thickness 3.0 mm
• Thermal drill thread M5
• Thread tapper size M5 x 0.8

Holzkraft

• Saw band length 6690 mm
• Delivery power 5.5 kW
• Extraction port diameter 2 x 140 mm
• Flywheel diameter 940 mm
• Frequency 50 Hz

Optimum

• Thermal drill max. material thickness 4.0 mm
• Thermal drill thread M8

Metallkraft

Metallkraft

• Cutting range 0° bundle (tube) 320 x 160 mm
• Motor power 1.3/1.8 kW
• Saw band length 3660 mm
• Cutting range +45° rectangular horiz. (hollow profile) 270 x 200 mm
• Cutting range +45° round (full material) 110 mm

Optimum

• Thermal drill max. material thickness 6.5 mm
• Thermal drill thread M10

Optimum

• Thermal drill max. material thickness 2.5
• Thermal drill thread 3/8 "
• Thread tapper pitch 16 TPI
• Thread tapper size 3/8"
• Thread tapper total length 100 mm
