Centre Lathe - OPTIturn TH 3610D (400v)

Description

  • Fully equipped mechanic lathes. TH 3610D with Digital Readout System DPA 21
  • Hardened and ground Z-axis guideway
  • Spindle mount Camlock DIN ISO 702-2 No. 5
  • Guaranteed concentricity of the spindle nose better than 0.015 mm
  • Gears and shafts hardened and ground,
    running in an oil bath in precision bearings
  • Motor protection switch, lockable main switch
  • Right / left rotation on bed sled switchable
  • leading spindle
  • Machine base with tool pockets
  • Emergency stop device with foot control
  • Safety handwheels with release function in the X and Z axis

TH 3610D:

  • Digital Readout System DPA 21
    • User-friendly membrane keypad, splash-proof, closed and glare-free
    • Higher work accuracy
    • The error rate is reduced
    • X, Z0, Z-axis with 8-digit display each
    • glass scales

Room amenities:

Switch cabinet

  • 24 volt DC power supply
  • All contractors and relays from Siemens or Schneider

Main spindle

  • Running in oil bath
  • Gear wheels smooth,
    hardened and ground

Carriage

  • Precisely worked
  • Handwheels with adjustable fine scale
    0.04 / 0.02 mm
  • Quadruple tool holder
  • All guides can be adjusted by wedge strips
  • Adjustment range upper slide ± 90 °

LED machine light

  • integrated into the chip protection

Bed

  • Heavily ribbed
  • cast iron
  • Induction hardened and precision ground

Tailstock

  • For taper turning ± 10 mm adjustable
  • Tailstock sleeve and hand wheel with adjustable fine-scale 0.025 mm

Substructure

  • Tool compartments on both sides

Chip pan

  • extractable
  • guide rails

Switch

  • with life cycle calculation
  • tested according to EN ISO 13849

Right-left switch

  • two channels
  • tested according to EN 23125

Handwheels

  • decoupled
  • tested according to EN 23125

Technical Specifications

Length (product) 1,930 mm
Width / depth (product) 725 mm
Height (product) 1,620 mm
Weight (net) 610 kg
Power drive motor 1.5 kW
Electrical voltage 400V
Phase (s) 3 Ph
Current Type ~
power frequency 50 Hz
Spindle taper Camlock DIN ISO 702-2 No. 5
Spindle bore / rod diameter 52mm
Centre height 180 mm
distance between centres 980 mm
Circumferential diameter over machine bed 356 mm
Circumference diameter in the bed bridge 516 mm
Turning length in the bed bridge 160 mm
bed width 187 mm
Speed range 70 – 2,000 min-1
Number of speed ranges 8 steps
Travel X-axis 100 mm
Travel Y-axis 170 mm
Tailstock MT 3
Tailstock quill stroke 120 mm
Tailstock quill diameter 42mm
Spindle taper MT 6
Steel holder pick-up height max. 16 mm
Feed area along 0.052 – 1.392 mm / rev
Number of feeds along 32
Feed area flat 0.014 – 0.38 mm / rev
Number of feeds plan 32
Gradient Metric 0.4 – 7 mm / rev
Number of slopes Metric 26
Gradient inches 56 – 4 Gg / in.
Number of slopes inches 34
