RFW 2
Description
- Trolley with 2 t maximum carrying capacity
- Low height and compact design
- For use on I-beams (DIN 1025-1)
- Quiet running characteristic by ball bearing
- No lateral hiking on the traverse by centric suspension of the pulley
- Adjustment to the support flange width is done by Ösentraverse with mating thread
- Standard anti-tilt device
Technical specifications
| Length approx. | 300 mm |
| Width / depth approx. | 277 mm |
| Height approx. | 208mm |
| Weight (net) approx. | 14 kg |
| Capacity | 2 t |
| Beam flange | 66-220 mm |
| Curve radius min. | 0.9 m |
| Suitable for carrier type | I 160? I 600 |
